Main
| Range of product | Modicon X80 |
| Product or component type | Analog input module |
Complementary
| Application specific I/O | HART |
| Product compatibility | BMEP58... processor BMXFTB20... terminal block ABE7CPA31 BMEXBP... backplane ABE7CPA02 ABE7CPA03 Head module BMECRA31210 |
| Electrical connection | 20 ways terminal block Telefast |
| Isolation between channels | Isolated |
| Analogue input number | 8 |
| Analogue input type | Current 4...20 mA |
| Analogue input resolution | 15 bits + sign |
| Input impedance | 250 Ohm internally protected resistor |
| Measurement error | 0.15 % of full scale 25 °C <= 0.3 % of full scale 0...60 °C |
| Temperature drift | 50 ppm/°C |
| Isolation voltage | 1000 V DC for 60 s between channels 1400 V DC for 60 s between channels and ground 1400 V DC for 60 s between channels and bus |
| Checks | Broken wire detection |
| Topology | Point-to-point |
| Function available | I/O mapping |
| Net weight | 0.233 kg |
Environment
| Ambient air temperature for operation | 0…60 °C |
| Directives | 2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility 2012/19/EU - WEEE directive |
| Standards | EN 61131-2 EN 61000-6-4 EN 61000-6-2 EN 61010-2-201 |
8 channels input HART module
