Specification Dimension (W×H×D) 482 × 88× 420 mm Mount dimension (W×H×D) 580 × 235 × 552 mm Net weight 9.3 kg Gross weight 12.5 kg
X-DCS2000/EN 1 Panel paper 6 Dry-contact input connector (8P) 2 Dry-contact output connector (6P) 4 Loudspeaker connector (16P) 2 Amplifier connector (4P) 2 AVC connector (8P) 2 DC power wiring terminal (4P) 1 Twist-pair cable (2 m) 1 Audio cable 1 AC power cable 1 Fuse (2A) 1 Product Instructions 1 CD-ROM 1
Technical Specifications
Parameter Value
Power Supply Main power supply ~100 - 240 V,50/60 Hz Backup power supply DC 21.5 V - 28.5 V DC power output DC24V/1A Max. input power 120 W Rated power 50 W Audio Input Auxiliary input 1V(0dBV) Input impedance 20 kΩ Frequency response 60 Hz - 16 kHz SNR > 85 dB Audio Output Audio output channels 4 Output signal 1.2V(1.6dBV) Record output 1V(0dBV) AVC Input Channels 4
Input signal
14mV(-37dBV) or 330mV (-9.6dBV)
Input impedance 20 kΩ Phantom power DC 24V,configured by switch Frequency response 60 Hz - 16 kHz SNR > 65 dB Loudspeaker Circuit Output channels 8, with circuit fault detection function
Max. output load
500 W (If the line supervision is used, the load shall be less than 250W.)
Trigger Input / Output Trigger input ports 8 Trigger output ports 8 (NO, NC and COM)
Max. working voltage AC 250 V / DC 30 V Max. working current 2.5 A Others Monitoring loudspeaker 10W / 8Ω Ethernet speed 10 M / 100 M Ethernet interface number 4 Storage space 1 GB Work Condition Humidity < 95 %, non condensing Operating temperature -10 °C ~ +55 °C Storage temperature -40 °C ~ +70 °C
